1 x 4" High-Performance Speaker - 100V Wooden Cabinet
TECHNICAL SPECIFICATIONS
ACOUSTICAL SPECIFICATIONS
• Freq. Response (-3 dB) : 99 Hz - 20 kHz
• Freq. Range (-10 dB) : 69 Hz - 20 kHz
• Rated Power : 30W AES, 120W Peak
• H Dispersion : 100° (- 6 dB)
• V Dispersion : 100° (- 6 dB)
• Nominal Impedance : 8 Ω
• Maximum SPL : 107 dB
• Fixed 10W Transformer Tap @ 100/70 V
• Impedance Toggle Switch to choose between
8 Ω or 100V operation
SYSTEM SPECIFICATIONS
• Recommended Subwoofers : See Systems
chart for compatible subwoofer
• Recommended Amplifiers : See Amplifier
load calculation chart
• Recommended System Control : Can be used
without DSP or with the PW-Six DSP for
voicing & tonal benefits
LF TRANSDUCER
• 4" Mid-High Driver with Axial Motors
• 30W AES, 120W Peak
• 2" Voice Coil - Ferrite Magnet
• Special High Strength axial magnetic motors
for controlled movement
• Flared Ports for Low Frequency Support
HF TRANSDUCER
• 1" HF Compression Driver
• 20W AES, 80W Peak
• 2 drivers connected in parallel
• 1" Voice Coil - Ferrite Magnet
• Vero Waveguide, delivers a consistent wide
angled coverage
HOUSING
• Angular Plywood Enclosure
• Water based, textured paint
• Perforated Stainless Steel Grill
• British Acoustics Signature Brown Paint
• Available in any RAL colour of your choice
• M6 Inserts
• VS Throne, VS 26 Yoke
• 35mm Pole Socket
• No handles, fricton paint finish for easy `
lifting
OPERATING PARAMETERS
• Operating Positions : Must be Flush
Mounted as per the manual into the ceiling
or used with the pendant accessory
• Maximum permitted ambient temperature
(Ta max) 55° C (124° F)
• Minimum permitted ambient temperature
(Ta min): -20° C (-4° F)
IP SPECIFICATIONS
• Standard Version : IP 42 - Offers basic
protection against dust & splashes
OPTIONAL ACCESSORIES
• See system chart for the System Accessories
SIZE
• Product : 127 x 127 x 101.6 mm (H x Wx D)
• Product: 5 x 5 x 4 inch (H x Wx D)
• Packed individually
WEIGHT
• Net : 2.5 Kgs
• Net : 5.5 Lbs
SHIPPING INFORMATION
• Carton Size
202 x 202 x 182 mm (H x W x D)
7.9 x 7.9 x 7 inch (H x W x D)
• Gross Weight : 2.6 Kgs / 5.7 Lbs
• Packed : Individually
