XD 22

2 x 3000W Class-D Amplifier

The XD Series is an advanced Class- D Amplifier with 2 Channel & 4 Channel Variants which combines very high power density with superb audio performance, Low AC Current Draw, and The M2 Module for Active PFC in the Input & Output stage the XD can also provide multi-channel amplification across the British Acoustics loudspeaker range.

The XD a full 8000 watts per channel into 4 ohms with all channels driven while remaining highly efficient. Its high efficiency reduces the energy drawn from the mains supply and ensures the power reserves needed to deliver superb sound under arduous live conditions.

The XD Series employs comprehensive protection functions to maintain safe operating conditions of both the amplifier and the loudspeakers driven — including a sophisticated loudspeaker limiter suite that incorporates peak, RMS and excursion limiting, as well as multiband limiting for passive 2-way systems.

TECHNICAL SPECIFICATIONS

ACOUSTIC

No. of Channels - 2

Power at 4 Ohms (Stereo Mode, All channels driven) - 3000W

Power at 8 Ohms (Stereo Mode, All channels driven) - 1800W

Bridged Power at 8 Ohms - 3600W

Bridged Power at 4 Ohms - 6000W

Signal to Noise Ratio (1 kHz, 8 Ohms) - - 100 dB

Damping Factor - > 1050

THD - < 0.02% THD / 4ohms and 8 ohms

Controls - Sensitivity Selection & Stereo, Bridge, Parallel Switch

AC Power Input - Universal power supply 100 - 240 VAC, 50 - 60 Hz

AESTHETIC

Enclosure - Ultra-Light Weight Steel Chassis

LED Screen - 4.5" LED Screen Display

Finish - Glossy Phantom Black Metallic Finish

Mounting System - 19" Standard Rack Mount Ears

DIMENSIONS

Height - 3.5" (2 RU)

Width - 19"

Depth - 17.5"

Weight - 14.8 Kgs
