FUZE PFX
Technical Data
FEATURES
400W LED 6,600K White LED Engine15000 Total Lumen Fixture Output
Framing and Effects Fixture
Zoom Range from 3° to 53°
Variable CMY, CTO and 8-Position Color Wheel
Dual High CRI Filters
7 Rotating and 11 Fixed Gobos
Dual Independent Prisms for Layering
Motorized Iris
Soft and Wash Frost Filters
SPECIFICATIONS
SOURCE
400W 6,600K Bright White LED Engine
20,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.
PHOTOMETRIC DATA
15000 Total Lumen Output
CRI 72 (Filter CRI 80, CRI 90)
Zoom Range 3° - 53°
Beam Angle
Field Angle
EFFECTS
Motorized Zoom
4 Rotating Full Blackout Framing Blades
+/- 60° Framing Index
2 Variable Frost Filters (Light and Wash)
Dual Independent Prisms (6 Facet linear & 6 Facet round)
Motorized Iris
Variable 16-bit Dimming Curves
High Speed Electronic Shutter and Strobe
Pan Angle: 540°
Tilt Angle: 270°
COLOR
CMY Color Mixing
Linear CTO Color Correction
7 Dichroic Colors including UV Filter
High CRI Filter 80+90
GOBOS
7 Rotating / Indexing Interchangeable Glass Gobos
11 Static Metal Gobos
CONTROL / CONNECTIONS
DMX Channels
16-bit Pan, Tilt, and Dimming Control
DMX Adjustable LED Frequency
DMX, Art-Net, sACN Protocol Support
RDM (Remote Device Management)
Aria x2 Wireless Device Management
4 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
Locking 5pin XLR Connector In/Out
Locking RJ45 Ethernet Connector In/Out
IP65 Locking Power Connector In/Out
USB Connection (Firmware Updates)
SIZE / WEIGHT
Length: 362mm (14.3”)
Width: 233mm (9.2")
Vertical Height: 637mm (25.14")
Weight: 22.7kg (50 lbs.)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
600W Max Power Consumption
-10°C to 45°C (14°F to 113°F)
BTU/hr (+/- 10%) 2047
