Faital Pro 21XL3000
Neodymium
Description
Faital Pro 21XL3000 is a 21 inch cone driver with a 165 mm voice coil and a neodymium magnet. The listing gives 3000 W AES power and 98 dB sensitivity on 8 ohm, covering 30 Hz to 1.5 kHz. The net weight is 21.5 kg. The published parameters make comparison with other drivers easy. Order it from VMT with GST billing and delivery across India.
Key features
- 21" cone driver with Neodymium magnet
- Voice coil 165 mm (6.5")
- 3000 W AES power on 8 ohm
- Sensitivity 98 dB (1 W / 1 m)
- Frequency range 30 Hz - 1.5 kHz
- Net weight 21.5 kg
Specifications
| Woofer | 21" |
|---|
| Power (RMS) | 3000 W |
|---|
| Frequency range | 30 Hz - 1.5 kHz |
|---|
| Impedance | 8 ohm |
|---|
| Sensitivity | 98 dB (1 W / 1 m) |
|---|
| Voice coil | 165 mm (6.5") |
|---|
| Magnet | Neodymium |
|---|
| Weight | 21.5 kg |
|---|
Manufacturer description
Nominal Specifications
| Nominal Diameter |
535 mm (21 in) |
| Overall Diameter |
547 mm (21.54 in) |
| Bolt Circle Diameter |
527 mm (20.75 in) |
| Baffle Cutout Diameter |
508 mm (20.00 in) |
| Depth |
279.5 mm (11.00 in) |
| Flange and Gasket Thickness |
16 mm (0.63 in) |
| Net Weight |
21.5 kg (47.4 lb) |
Shipping Box
(Single Carton Box) |
580 x 580 x 323 mm
(22.8 x 22.8 x 12.7 in) |
| Shipping Weight |
23.5 kg (51.8 lb) |
Technical Parameters
| Nominal Impedance |
8 Ohm |
| Minimum Impedance |
7 Ohm |
| AES Power Handling (1)
|
3000 W |
| Maximum Power Handling (2)
|
6000 W |
| Sensitivity (1W/1m) |
98 dB |
| Frequency Range |
30÷1500 Hz |
| Voice Coil Diameter |
165 mm (6.5 in) |
| Winding Material |
Al |
| Former Material |
Glass Fiber |
| Winding Depth |
40 mm (1.57 in) |
| Magnetic Gap Depth |
14 mm (0.55 in) |
| Flux Density |
1.4 T |
| Magnet |
Neodymium Ring |
| Basket Material |
Aluminum |
| Demodulation |
Aluminum Ring |
| Cone Surround (3)
|
Triple Roll |
| NET Air Volume filled by Loudspeaker |
13.0 dm^3 (0.459 ft^3) |
| Spider Profile |
2x non-adjacent constant height waves |
|
Thiele and small parameters
| Fs |
30 Hz |
| Re |
5.9 Ohm |
| Qes |
0.25 |
| Qms |
8.8 |
| Qts |
0.25 |
| Vas |
284.6 dm^3 (10.05 ft^3) |
| Sd |
1744 cm^2 (270.32 in^2) |
| Xmax (4)
|
17.67 mm |
| Xdamage (5)
|
40 mm |
| Mms |
420.0 g |
| Bl |
43.0 N/A |
| Le |
1.25 mH |
| Mmd |
337.7 g |
| Cms |
0.07 mm/N |
| Rms |
9.0 kg/s |
| Eta Zero |
3.0 % |
| EBP |
119 Hz |
PART NUMBER (P/N)
| Push Terminals - 8 Ohm Version |
05404427 |
Notes:
|
(1) 2 Hours Test According to AES 2-1984 Rev. 2003 |
|
(2) Maximum power is defined as 3dB greater than nominal power. |
|
(3) Treated Polycotton |
|
(4) Xmax= [(winding depth - magnetic gap depth)/2] + (magnetic gap depth/3) |
|
(5) Maximum excursion before permanent damage |
|
